Infrared Bar Heaters + IP65
IBH 3 box.png

Infrared Bar Heaters + IP65

https://www.infraredheaterpanels.co.uk/web/image/product.template/159/image_1920?unique=52bc3fa

Medium Intensity Infrared Bar Heaters (IBH) for all environments. Built for UK voltages.


For expansive spaces like warehouses, factories, and large halls, we have a selection of medium intensity infrared heaters. These heaters can effectively and economically warm large, high buildings while using long (but not far) wave infrared technology. Their IP65 rating makes them perfect for challenging industrial environments and sterile settings.

Key features of these heaters include:

  • A large contoured, high emissivity heating plate that efficiently heats objects and people rather than the air. Constructed with highly conductive, anodized (black) Aluminium, the emitting plate is not only the key to this heaters great performance, it looks great as well.
  • Embedded within the plate, is a metal/ ceramic tubular heating element. The fully encased element is protected against oxidation thereby ensuring many years of operating life. In contrast, halogen / quartz / carbon elements all have limited operating lives (<8,000 hours).
  • Internal insulation (Rockwool) reduce rear panel energy losses, further enhancing performance.
  • Fully adjustable bracket system, allows independent movement thereby eliminating thermal expansion stresses.
  • These heaters come with our own 10 year guarantee.

Data Sheet:

Part
No
Power
(watt)
Voltage
(volt)

Weight
(kgs)
Size
(mm)
​Heating
Area​ (m2)

IBH1500+

1500

220-240

5.3

1045x177x60

15

IBH1800+

1800

220-240

6.1

1225x177x60

18

IBH2400+

2400

220-240

7.3

1505x177x60

24

IBH3200+

3200

220-240

9.3

1915x177x60

32

Property Value
Usage Medium Intensity Heater ideal for wide open spaces, enclosures. Not suitable for windy conditions.
Temperature 300°C
Element Tubular Aero-Tech heating, encased in ceramic within stainless steel sheath. Life expectancy 50000 hours
Operating Voltage 216 - 253 VAC
IP Rating IP65
Colour Black
Warranty 10 years
Certifications & Compliance EN 60335-1:2012+A11:2014+A13:2017+A1:2019+A14:2019+A2:2019 EN 60335-2-30:2009+A11:2012 EN 62233:2008
Manufactured By Asian Supplier, QC and CE'ed by IHP
